16800DWT oil/chemical tanker

Length overall：                         about  142.50 m

Length BP：                              134.50 m

Breadth, moulded                         23.00 m

Depth moulded                    12.60 m

Draft designed：                           8.95 m

Deadweight：                             about  16800 t

Tank capacity：

Cargo Tank Capacity (incl. slop tanks), 100% full： about 19,200m3

slop tanks：                               about 2×100m3

HFO, 100% full (Including day/settling tank)：         about 800m3

Marine diesel oil , 100% full(Including day/settling tank)：about 80m3

Lub.  oil Tank, 100% full：                 about 20m3

Fresh water , 100% full：                        about 230m3

 Ballast Tank Capacity, 100% full：             about 7,500m3

Speed &Cruising Range：

 About 13.0 knots at 90% MCR.

The ship to be designed for unrestricted service with a cruising

range of 9000 nautical miles at a service speed of 13.0 knots.
